Double Blower Motor - SPAL 30000126
SKU
74067
Views: 0
Part No. 74067
For Case IH Magnum 235 with Serial No. up to Z8RZ06299.
For Case IH Maxxum 115, 125, 135, 140, 150, 180 with Iveco Engine.
Overall Length: 351mm.
Overall Height: 140mm.
Overall Width: 168mm.
Mounting Base Length: 351mm.
Mounting Base Width: 136mm.
12v.
Double Blower Wheel.
690 CFM.
31.1A Current Draw.
3 Speeds. Aluminium Resistor Supplied.
Jumper Between Electric Motor And Resistor (No Wire Harness Included).
Maximum Airflow (At Zero Static Pressure): 690CFM (1170m³/h).
Standard Features: Long Life.
Operating Voltage: 12v.
IP Rating: IP30.
SPAL Type / Description: 006-A39-22 RA3VCV.
RA: Aluminium Resistor.
3V: 3 Speeds.
CV: Jumper Between Electric Motor And Resistor (Without Wire Harness).
Mounting Bolt/Screw: M4 Screw.
Mounting Torque: 3(+1/-0) Nm.
Certifications: UNI EN ISO 9001:2008, ISO TS 16949, ISO 14001.
Product Details
Double Blower Motor - SPAL 30000126Fits Models
New Holland
T6. SERIES
- T6.175, T6.120, T6.140, T6.165, T6.150, T6.160, T6.155
T6000 SERIES
- T7050, T7040, T6060, T6050, T7070, T6070, T7030, T6090, T6020, T6080, T7060, T6010, T6030, T6040
T7. SERIES
- T7.235, T7.260, T7.270, T7.210, T7.170, T7.185, T7.250, T7.200, T7.220
T8. SERIES
- T8.330, T8.410, T8.300, T8.390, T8.420, T8.320, T8.350, T8.275, T8.360, T8.380
TSA SERIES
- TS100A, TS115A, TS120A, TS110A, TS135A, TS130A, TS125A
Out of stock
