Quick Release Coupling - Female - Body Size 1/2"

Quick Release Coupling - Female - Body Size 1/2" - Thread Size 3/4" - 16 UNF

This series of ISO A female couplings are designed primarily for the agricultural industry and incorporate a push/pull design. The coupling is panel mounted using circlip grooves on the locking sleeve.

Body Size: 1/2”

Thread: 3/4" - 16 UNF

D1: 38.1mm / 1.5"

L1: 66mm / 2.6"

A/F: 27mm / 1.06"

APPLICATIONS

• Agricultural

• Construction

• Mobile

• General hydraulics

FEATURES

• Can be connected with standard ISO A 1/2” male couplings

• Release mechanism protects coupling and hose from damage in event of accidental separating force

• Locking ball system allows quick connection

• Bidirectional flow

SPECIFICATIONS

• Operating temperatures -40°C (-40°F) to 106°C (223°F)

• Carbon steel with trivalent plating

• Fitted with NBR seals

• Conforms to ISO 7241 : 2014 A

PERFORMANCE CHARACTERISTICS

• Maximum Working Pressure (Coupled) - 320 bar (Flow in Litres Per Minute) - 4640 PSI (Flow in Gallons Per Minute)

• Burst Pressure (Coupled) - 1500 bar (Flow in Litres Per Minute) - 21750 PSI (Flow in Gallons Per Minute)

• Rated Flow - 45 bar (Flow in Litres Per Minute) – 12 PSI (Flow in Gallons Per Minute)
