Quick Release Coupling - Male - Body Size 1/2"
SKU
50234
Views: 0
Part No. 50234
Quick Release Coupling - Male - Body Size 1/2" - Thread Size 3/4"-16 UNF
This series of ISO A couplings are the ideal choice where a tough, durable product of superior quality is required. They are perfectly suited to agricultural and industrial applications.
Body Size: 1/2”
Thread: 3/4"-16 UNF
D2: 20.5mm / 0.81"
L2: 43.5mm / 1.71"
A/F: 27mm / 1.06"
APPLICATIONS
• Agricultural
• Construction
• Mobile
• General hydraulics
FEATURES
• Poppet valves have balanced springs
• Locking ball system allows quick connection
• Bidirectional flow
SPECIFICATIONS
• Operating temperatures -40°C (-40°F) to 106°C (223°F)
• Carbon steel with trivalent plating
• Fitted with NBR seals
• Conforms to ISO 7241 : 2014 A
PERFORMANCE CHARACTERISTICS
• Maximum Working Pressure (Coupled) - 320 bar (Flow in Litres Per Minute) - 4640 PSI (Flow in Gallons Per Minute)
• Burst Pressure (Coupled) - 1500 bar (Flow in Litres Per Minute) - 21750 PSI (Flow in Gallons Per Minute)
• Rated Flow - 45 bar (Flow in Litres Per Minute) – 12 PSI (Flow in Gallons Per Minute)
Product Details
Quick Release Coupling - Male - Body Size 1/2"Fits Models
FORD & FORDSON
10 SERIES
- 3910, 3610, 2810, 6810, 8210, 7810, 6610, 5610, 6410, 6710, 2610, 2910, 4110, 4610, 7710
100 SERIES
1000 SERIES
In stock
