Double Blower Motor - SPAL 30002226
SKU
80162
Views: 0
Part No. 80162
For Case IH CX Series with Low Profile Cab.
For Case IH Maxxum 100, 110, 120, 130 with Iveco Engine
Product Info
- Overall Length: 351mm
- Overall Height: 140mm
- Overall Width: 168mm
- Mounting Base Length: 351mm
- Mounting Base Width: 136mm
- 12v
- Double Blower Wheel
- 608 CFM
- 24.4A Current Draw
- Single Speed
- Wire Harness Not Included
- Maximum Airflow (At Zero Static Pressure): 608CFM (1030m³/h)
- Operating Voltage: 12v
- IP Rating: IP30
- SPAL Type / Description: 006-A45-22
- Mounting Bolt / Screw: M4 Screw
- Mounting Torque: 3(+1/-0) Nm
- Certifications: UNI EN ISO 9001:2008, ISO TS 16949, ISO 14001
Product Details
Double Blower Motor - SPAL 30002226Fits Models
CASE INTERNATIONAL
CX SERIES
- CX100, CX80, CX90
JX SERIES
- JX55, JX60, JX65, JX70, JX75, JX80, JX85, JX90, JX95
MAXXUM MX SERIES ( 1997 - 2002 )
- MX100, MX110, MX120, MX135, MX150, MX170
MAXXUM MXM SERIES ( 2002 - 2007 )
- MXM120, MXM130, MXM140, MXM155, MXM175, MXM190
