Double Blower Motor - SPAL 30001803

SKU

76473

Part No. 76473

Overall Length: 317mm.

Overall Height: 112mm.

Overall Width: 125mm.

Mounting Base Length: 317mm.

Mounting Base Width: 86mm.

12v.

Double Blower Wheel.

360 CFM.

14.1A Current Draw.

3 Speeds. Small Resistor Supplied.

Wire Harness With AMP Connector Supplied.

Maximum Airflow (At Zero Static Pressure): 360FM (610m³/h).

Standard Features: Long Life.

Operating Voltage: 12v.

IP Rating: IP30.

SPAL Type / Description: 005-A45-02 L301 RPA3VCB.

CB: Wire Harness With AMP Connector.

RPA: Small Resistor.

3V: 3 Speeds.

Mounting Bolt/Screw: M4 Screw.

Mounting Torque: 3(+1/-0) Nm.

Certifications: UNI EN ISO 9001:2008, ISO TS 16949, ISO 14001.

Product Details

Double Blower Motor - SPAL 30001803

Fits Models

CASE INTERNATIONAL

JX SERIES

JX1060C, JX1090U, JX70U, JX1080U, JX1100U, JX1070C, JX1070U, JX80U, JX1075C, JX90U

In stock
