Clutch Kit (With Bearings)
SKU
628103307
Views: 0
Part No. 628103307
128005511 - Single Cover. 6 Bolt. 280mm. With Fixed PTO Plate 1" 5/8 and 10 Splines.
328017541 - Transmission Plate. 280mm. 10 Spline. Spline O/D 1"1/8. Torsion Sprung with compensating springs. No Axial cushion. 6 Pair of Pads on a plate with 8 spaces.
500104650 - Transmission Bearing. Bore 60.2mm. OD 101.6mm. Depth 22.28mm. Bearing Only. Can be equipped with different release bearings compare with old core.
410002640 - Flywheel Bearing. Bore 20mm. OD 47mm. Depth 14mm. Deep groove ball bearing.
328017541 - Transmission Plate. 280mm. 10 Spline. Spline O/D 1"1/8. Torsion Sprung with compensating springs. No Axial cushion. 6 Pair of Pads on a plate with 8 spaces.
500104650 - Transmission Bearing. Bore 60.2mm. OD 101.6mm. Depth 22.28mm. Bearing Only. Can be equipped with different release bearings compare with old core.
410002640 - Flywheel Bearing. Bore 20mm. OD 47mm. Depth 14mm. Deep groove ball bearing.
Product Details
Clutch Kit (With Bearings)Fits Models
CASE INTERNATIONAL
3200 SERIES
4200 SERIES
- 4230, 4220, 4240, 4210
54 SERIES
- 454
74 SERIES
- 674, 574, 474
75 SERIES
- 475
84 SERIES
- 884, 784, 684, 484, 584
85 SERIES
- 685, 385, 485XL, 885, 585, 485
95 SERIES
- 595, 895, 395, 495
INDUSTRIAL
- 268, 248, 258
Out of stock
